BUBBLE FORMATION AT TWO ADJACENT SUBMERGED ORIFICES IN INVISCID FLUIDS

Bashir H Arebi; W. Dempster

doi:10.66411/jer.v10i10.171

Authors

Bashir H Arebi Department of Nuclear Engineering, Al-Fateh University, Tripoli, Libya Author
W. Dempster Strathclyde University, Glasgow, U.K Author

DOI:

https://doi.org/10.66411/jer.v10i10.171

Keywords:

Bubble formation and detachment, Submerged orifices, M orificesultiple

Abstract

A theoretical model has been developed as an extension of single orifice bubble formation to investigate the growth and detachment of vapor/ gas bubbles formed at two adjacent submerged orifices in inviscid fluids. The mathematical model treats the two bubbles as an expanding control volume moving to the line of centers above a wall. The movement of the bubbles is obtained by application of force balance acting on the bubble and accounts for surface tension, buoyancy, steam momentum and liquid inertia effects. The liquid inertia effects are determined by applying inviscid and irrotational flow assumptions to allow potential flow theory to calculate the liquid velocity field which then allows the pressure distribution to be calculated. The model is extended to include the mass and energy equations to model the steam bubble formation in sub-cooled water. The theoretical results are compared with the available experimental data of bubble formation during constant mass flow steam bubble formation at two submerged upward facing orifices in sub-cooled water. The model was validated by available experimental data for the growth and detachment processes of two adjacent 1 mm orifices at system pressures of 2 and 3 bars, flow rates of 1.2-4 g/min at sub-cooling of 3.5-35 ^oC. The comparisons of theory and experiments indicate that the model successfully predicts the bubbles growth and detachment for the range of conditions studied

References

[1] Rayleigh, L "On the pressure developed in a liquid during the collapse of a spherical Cavity", Phil. Mag, Vol. 34, (1917), pp 94-98 DOI: https://doi.org/10.1080/14786440808635681

[2] Dempster W. m. and Arebi B. H. "Experimental characteristics of steam bubble growth at orifices in sub-cooled liquid" Int. Comm. Heat Mass Transfer, Vol. 28, No. 4, pp 467 -477, 2001. DOI: https://doi.org/10.1016/S0735-1933(01)00251-2

[3] Arebi B. and Dempster W. M. "Theoretical model for the growth and detachment of condensing steam bubbles at submerged orifice" Two- phase flow modelling and experimentation, 1999 pp 397-404

[4] Davidson, J. F., and Schuler, B. O. G., "Bubble formation at an Orifice in an inviscid Liquid", Trans. Instn. Chem. Engrs., Vol. 38, (1960), pp 335-342.

[5] Simpson, H. C., Bradford, A. M. and Tao, Z. "The formation of steam bubble at an orifice submerged in subcooled water", European Two-Phase Flow Group Meeting, Paris, (1989).

[6] Cho, S. C. and Lee, W. K., "Steam bubble formation at a submerged orifice in quiescent water", Chem. Eng. Sci., Vol. 46, No. 3, (1991), pp 789-795. DOI: https://doi.org/10.1016/0009-2509(91)80185-2

[7] Schmidt, H., "Bubble formation and heat transfer during dispersion of superheated steam in saturated water - I: Bubble size and bubble detachment at single orifices", Int. J. Heat Trans., Vol.20, (1976), pp 635-646. DOI: https://doi.org/10.1016/0017-9310(77)90050-3

[8] Ruzicka M., Drahos J., Zahrdnik N., Thomas N. H. "Natural modes of multi-orifice bubbling from a Common Plnum" Chem. Eng. Sci. vol. 54 (1999) pp 5223-5229 DOI: https://doi.org/10.1016/S0009-2509(99)00243-2

[9] Ruzicka M., Drahos J., Zahrdnik N., Thomas N. H. "Structure of gas pressure signal at two orifices bubbling from a common plenum" Chem. Eng. Sci. vol. 55 (2000) pp 421-429. DOI: https://doi.org/10.1016/S0009-2509(99)00337-1

[10] Shuki Xie, Reginald H. Tan "Bubble formation at multiple orifices-bubbling synchronicity and frequency" Chem. Eng. Sci. Vol. 58 (2003) pp 4639-4647 DOI: https://doi.org/10.1016/j.ces.2003.06.002

[11] Pereira Dias. M. I. "Bubble formation at multiple orifice plate submerged in quiescent liquid" PhD. thesis, University Libre De Bruxelles and Von Karman Institute for Fluid Dynamics (1999).
